Matična ploča Gigabyte B550 Aorus Elite V2 DDR4

CPU
– AMD AM4 Socket, podrška za Ryzen™ 5000 / 5000 G-Series / 4000 G-Series / 3000 / 3000 G-Series procesore
– Detaljan popis podržanih procesora dostupan na službenoj stranici

Chipset
– AMD B550

Memory
– 4 x DDR4 DIMM utora, max. 128 GB (32 GB po DIMM-u)
– Podržane brzine: DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz
– Dual channel arhitektura
– Podrška za ECC un-buffered DIMM (ovisno o CPU)
– Podrška za non-ECC un-buffered DIMM 1Rx8/2Rx8/1Rx16
– Podrška za XMP profile

Onboard Graphics
– 1 x DisplayPort (max. 5120×2880@60 Hz, DP 1.4, HDCP 2.3, HDR)
– 1 x HDMI (max. 4096×2160@60 Hz, HDMI 2.1, HDCP 2.3, HDR)
– Maksimalno dijeljena memorija: 16 GB

Audio
– Realtek® ALC1200 codec
– HD Audio, 2/4/5.1/7.1-kanalni izlaz
– Podrška za S/PDIF Out

LAN
– Realtek® 2.5GbE LAN (2.5/1 Gbit/100 Mbit)

Expansion Slots
– 1 x PCIe x16 (CPU):
• Ryzen™ 5000/3000: PCIe 4.0 x16
• Ryzen™ 5000 G/4000 G/3000 G: PCIe 3.0 x16
– 1 x PCIe x16 (Chipset, PCIEX2): PCIe 3.0 x2
– 1 x PCIe x16 (Chipset, PCIEX1_2): PCIe 3.0 x1
– 1 x PCIe x1 (Chipset, PCIEX1_1): PCIe 3.0 x1

Storage
– 1 x M.2 (M2A_CPU, 2242/2260/2280/22110):
• Ryzen™ 5000/3000: SATA + PCIe 4.0 x4/x2
• Ryzen™ 5000 G/4000 G/3000 G: SATA + PCIe 3.0 x4/x2
– 1 x M.2 (M2B_SB, 2242/2260/2280/22110): SATA + PCIe 3.0 x4/x2
– 4 x SATA 6Gb/s (Chipset), RAID 0/1/10

USB
CPU:
– Ryzen™ 5000/3000: 2 x USB 3.2 Gen2 Type-A (crveni, stražnji panel)
– Ryzen™ 5000 G/4000 G/3000 G: 2 x USB 3.2 Gen1 (crveni, stražnji panel)
– 2 x USB 3.2 Gen1 (stražnji panel)
Chipset:
– 1 x USB Type-C (USB 3.2 Gen1, interni header)
– 1 x USB 3.2 Gen1 (stražnji panel)
– 2 x USB 3.2 Gen1 (interni header)
– 2 x USB 2.0 (stražnji panel)
– 4 x USB 2.0 (interni header)

Internal I/O
– 1 x 24-pin ATX
– 1 x 8-pin ATX 12V
– 2 x M.2 Socket 3
– 4 x SATA 6Gb/s
– 1 x CPU Fan header
– 1 x Water Cooling CPU Fan header
– 3 x System Fan headera
– 1 x CPU cooler LED/RGB header
– 2 x Addressable LED headera
– 2 x RGB LED headera
– 1 x Front Panel header
– 1 x Front Panel Audio header
– 1 x USB Type-C (USB 3.2 Gen1)
– 1 x USB 3.2 Gen1 header
– 2 x USB 2.0 headera
– 1 x TPM header
– 1 x Clear CMOS jumper

Back Panel I/O
– 1 x DisplayPort
– 1 x HDMI
– 2 x USB 3.2 Gen2 Type-A (crveni, samo Ryzen™ 5000/3000)
– 3 x USB 3.2 Gen1
– 2 x USB 2.0
– 1 x Q-Flash Plus gumb
– 1 x RJ-45 LAN
– 1 x optički S/PDIF Out
– 5 x audio jackova

I/O Controller
– iTE® I/O Controller Chip

Monitoring
– Detekcija napona, temperature, brzine ventilatora
– Detekcija protoka vode
– Upozorenje na pregrijavanje
– Upozorenje na kvar ventilatora
– Kontrola brzine ventilatora

BIOS
– 256 Mbit flash
– AMI UEFI BIOS
– PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features
– APP Center (EasyTune, RGB Fusion, Smart Backup, System Information Viewer)
– Podrška za Q-Flash Plus i Q-Flash

Bundled Software
– Norton® Internet Security (OEM)
– LAN bandwidth management

OS
– Windows® 11 64-bit
– Windows® 10 64-bit

Form Factor
– ATX, 30.5 cm x 24.4 cm
