Matična ploča Asus TUF Gaming B850-PLUS WiFi

CPU
– AMD AM5 Socket, podrška za Ryzen™ 9000 / 8000 / 7000 seriju procesora
– Detaljan popis podržanih procesora dostupan na ASUS web stranici

Chipset
– AMD B850

Memory
– 4 x DDR5 DIMM utora, max. 256 GB
– Podržane brzine: do 8000+ MT/s (OC) s Ryzen™ 9000 / 8000 / 7000 procesorima
– ECC i Non-ECC, un-buffered DIMM
– Dual channel arhitektura
– Podrška za AMD EXPO™ profile i ASUS AEMP
– DDR5 Non-ECC memorija podržava On-Die ECC

Graphics
– 1 x DisplayPort (DP 1.4, max. 8K@30 Hz)
– 1 x HDMI (HDMI 2.1, max. 4K@60 Hz)
* Ovisno o CPU-u

Expansion Slots
Ryzen™ 9000/7000:
– 1 x PCIe 5.0 x16 (x16 mod)
Ryzen™ 8000:
– 1 x PCIe 4.0 x16 (x8/x4 mod)
Chipset:
– 1 x PCIe 4.0 x16 (x4 mod, dijeli bandwidth s M.2_3)
– 2 x PCIe 4.0 x1
* PCIEX16(G4) se isključuje kada M.2_3 radi

Storage
– 3 x M.2 + 4 x SATA 6Gb/s
Ryzen™ 9000/7000:
– M.2_1: PCIe 5.0 x4 (2280)
– M.2_2: PCIe 4.0 x4 (2242/2260/2280/22110)
Ryzen™ 8000:
– M.2_1: PCIe 4.0 x4 (2280)
– M.2_2: PCIe 4.0 x4/x2 (2242/2260/2280/22110)
Chipset:
– M.2_3: PCIe 4.0 x4 (2280, dijeli bandwidth s PCIEX16(G4))
– 4 x SATA 6Gb/s
– Podrška za RAID 0/1/5/10 (Ryzen™ 9000), RAID 0/1 (Ryzen™ 8000), RAID 0/1/10 (Ryzen™ 7000)

Ethernet
– Realtek® 2.5Gb Ethernet
– TUF LANGuard

Wireless & Bluetooth
– Wi-Fi 7 (802.11be), 2×2, 2.4/5/6 GHz, 160 MHz bandwidth, do 2.9 Gbps
– Bluetooth® 5.4
* Wi-Fi 7 zahtijeva Windows 11 24H2 ili noviji

USB
Stražnji (10 portova):
– 1 x USB 20Gbps (Type-C)
– 3 x USB 10Gbps (Type-A)
– 4 x USB 5Gbps (Type-A)
– 2 x USB 2.0 (Type-A)
Prednji (7 portova):
– 1 x USB 10Gbps (Type-C)
– 1 x USB 5Gbps header (2 porta)
– 2 x USB 2.0 headera (4 porta)
* USB Type-C PD: max. 5V/3A

Audio
– Realtek® ALC1220P, 7.1 Surround HD Audio
– Impedance sense, jack-detection, multi-streaming, front panel jack-retasking
– 120 dB SNR stereo playback, 113 dB SNR recording
– Do 32-bit/192 kHz playback (stereo)
– Audio Shielding, premium kondenzatori, zasebni PCB slojevi, audio cover, de-pop circuit

Back Panel I/O
– 1 x USB 20Gbps (Type-C)
– 3 x USB 10Gbps (Type-A)
– 4 x USB 5Gbps (Type-A)
– 2 x USB 2.0 (Type-A)
– 1 x DisplayPort
– 1 x HDMI
– 1 x Wi-Fi modul
– 1 x Realtek 2.5Gb Ethernet
– 5 x audio jackovi
– BIOS FlashBack™ gumb

Internal I/O
– 1 x 24-pin ATX
– 2 x 8-pin CPU_PWR
– 1 x CPU Fan header
– 1 x CPU OPT Fan header
– 1 x AIO Pump header
– 4 x Chassis Fan headera
– 3 x M.2 slotova
– 4 x SATA 6Gb/s
– 1 x USB 10Gbps (Type-C)
– 1 x USB 5Gbps header (2 porta)
– 2 x USB 2.0 headera (4 porta)
– 3 x Addressable Gen2 RGB headera
– 1 x Clear CMOS header
– 1 x Chassis Intrusion header
– 1 x COM port header
– 1 x Front Panel Audio
– 1 x System Panel header
– 1 x Thunderbolt™ (USB4®) header

Special Features
– ASUS TUF PROTECTION (DIGI+ VRM, ESD Guards, LANGuard, Overvoltage, SafeSlot, Steel I/O)
– ASUS Q-Design (M.2 Q-Latch, PCIe Q-Release, Q-Antenna, Q-DIMM, Q-LED, Q-Dashboard, Q-Slot)
– ASUS Thermal Solution (M.2 heatsink, VRM heatsink)
– ASUS EZ DIY (BIOS FlashBack™, LED, ProCool, pre-mounted I/O shield, SafeDIMM)
– Aura Sync (Addressable Gen2 RGB)

Software
– Armoury Crate (Aura Creator, Aura Sync, Fan Xpert 4, Power Saving)
– ASUS DriverHub, GlideX, TurboV Core, TUF GAMING CPU-Z, DTS Audio Processing
– Norton 360 for Gamers (60 dana), WinRAR (40 dana)

UEFI BIOS
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI BIOS EZ Mode
– ASUS MyHotkey
– 256 Mb Flash ROM, AMI UEFI BIOS

Manageability
– WOL by PME, PXE

Accessories
– 2 x SATA kablova
– ASUS WiFi Q-Antenna
– TUF GAMING naljepnica
– 2 x M.2 gumeni paketi
– Quick start guide

OS
– Windows® 11

Form Factor
– ATX, 30.5 cm x 24.4 cm
