Matična ploča Asus Prime B660M-K DDR4

CPU
– Intel® Socket LGA1700, podrška za Intel® Core™ 14., 13. i 12. generaciju, Pentium® Gold i Celeron® procesore*
– Podrška za Intel® Turbo Boost Technology 2.0 i Intel® Turbo Boost Max Technology 3.0**
* Detaljan popis podržanih procesora: www.asus.com
** Podrška ovisi o tipu procesora

Chipset
– Intel® B660

Memory
– 2 x DIMM utora, max. 64 GB DDR4
– Podržane brzine: 5333(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133
– Dual channel arhitektura
– Podrška za Intel® XMP profile

Graphics
– 1 x D-Sub
– 1 x HDMI® (max. 4K@60Hz, HDMI 2.1)
* Specifikacije ovise o CPU-u

Expansion Slots
CPU:
– 1 x PCIe 4.0/3.0 x16
Chipset:
– 2 x PCIe 3.0 x1

Storage
– 2 x M.2 utora + 4 x SATA 6Gb/s
CPU:
– M.2_1 (2242/2260/2280, PCIe 4.0 x4)
Chipset:
– M.2_2 (2242/2260/2280, PCIe 4.0 x4)
– Podrška za Intel® RST, RAID 0/1/5/10
– Podrška za Intel® Optane Memory H Series na PCH M.2 slotovima

Ethernet
– 1 x Realtek 1Gb LAN
– ASUS LANGuard

USB
Stražnji (6 portova):
– 4 x USB 3.2 Gen1 (Type-A)
– 2 x USB 2.0 (Type-A)
Prednji (6 portova):
– 1 x USB 3.2 Gen1 header (2 porta)
– 2 x USB 2.0 headera (4 porta)

Audio
– Realtek 7.1 Surround HD Audio CODEC
– Jack-detection, Multi-streaming, Front Panel Jack-retasking
– Do 24-bit/192 kHz playback
– Audio Shielding, premium kondenzatori, zasebni PCB slojevi
* Za 7.1 izlaz potreban je kućišni HD audio modul

Back Panel I/O
– 4 x USB 3.2 Gen1 (Type-A)
– 2 x USB 2.0 (Type-A)
– 1 x D-Sub
– 1 x HDMI
– 1 x Realtek 1Gb LAN
– 3 x audio jackovi
– 1 x PS/2 combo port

Internal I/O
– 1 x CPU Fan (4-pin)
– 1 x Chassis Fan (4-pin)
– 1 x 24-pin ATX
– 1 x 8-pin +12V
– 2 x M.2 utora
– 4 x SATA 6Gb/s
– 1 x USB 3.2 Gen1 header (2 porta)
– 2 x USB 2.0 headera (4 porta)
– 1 x RGB header
– 1 x Clear CMOS header
– 1 x COM header
– 1 x Front Panel Audio (AAFP)
– 1 x S/PDIF Out header
– 1 x Speaker header
– 1 x SPI TPM header
– 1 x System Panel header

Special Features
– ASUS 5X PROTECTION III (DIGI+ VRM, LANGuard, Overvoltage, SafeSlot Core, Steel I/O)
– ASUS Q-Design (Q-DIMM, Q-Slot)
– ASUS EZ DIY (ProCool)
– ASUS Thermal Solution (VRM heatsink)
– ASUS Lighting Control (RGB header)

Software
– Armoury Crate
– AI Suite 3 (TurboV EVO, EPU, DIGI+ VRM, Fan Xpert)
– ASUS CPU-Z
– Norton Antivirus (trial)
– WinRAR
UEFI BIOS:
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI BIOS EZ Mode

BIOS
– 128 Mb Flash ROM, AMI UEFI BIOS

Manageability
– WOL by PME, PXE

Accessories
– 2 x SATA kablova
– 1 x I/O Shield
– 2 x M.2 anchors
– 1 x Support DVD
– 1 x korisnički priručnik

OS
– Windows® 11 64-bit, Windows® 10 64-bit

Form Factor
– microATX, 24.4 cm x 21.1 cm
